| Device | Min.Output Power(W) | Min.Efficiency (%) | Min.Gain (dB) | Test Frequency (MHz) | Operating Voltage(V) | Package Type | Single-Ended/ Push-Pull | Application Frequency | Active FET Configutation | Breakdown Voltage(V) |
| D1201UK | 10 | 50 | 10 | 500 | 12.5 | DP | SINGLE-ENDED | 1-500MHz | 1 | 40 |
| D1202UK | 20 | 50 | 10 | 400 | 12.5 | DP | SINGLE-ENDED | 1-500MHz | 2 | 40 |
| D1203UK | 30 | 50 | 10 | 175 | 12.5 | DM | SINGLE-ENDED | 1-200MHz | 3 | 40 |
| D1204UK | 30 | 50 | 10 | 175 | 12.5 | DT | SINGLE-ENDED | 1-200MHz | 3 | 40 |
| D1207UK | 20 | 50 | 10 | 400 | 12.5 | DQ | PUSH-PULL | 1-500MHz | 1+1 | 40 |
| D1208UK | 40 | 50 | 10 | 400 | 12.5 | DK | PUSH-PULL | 1-500MHz | 2+2 | 40 |
| D1209UK | 20 | 50 | 10 | 400 | 12.5 | DK | PUSH-PULL | 1-500MHz | 1+1 | 40 |
| D1210UK | 10 | 50 | 13 | 175 | 12.5 | DA | SINGLE-ENDED | 1-175MHz | 1 | 40 |
| D1211UK | 10 | 50 | 10 | 500 | 12.5 | S08 | SINGLE-ENDED | 1-500MHz | 1 | 40 |
| D1212UK | 60 | 50 | 10 | 175 | 12.5 | DH | PUSH-PULL | 1-200MHz | 3+3 | 40 |
| D1213UK | 6 | 50 | 8 | 500 | 7.2 | DBC1 | SINGLE-ENDED | 1-500MHz | 2 | 40 |
| D1217UK | 40 | 50 | 10 | 400 | 12.5 | DD | PUSH-PULL | 1-500MHz | 2+2 | 40 |
| D1218UK | 60 | 50 | 10 | 175 | 12.5 | DD | PUSH-PULL | 1-200MHz | 3+3 | 40 |
| D1221UK | 10 | 50 | 10 | 175 | 12.5 | DW | SINGLE-ENDED | 1-175MHz | 1 | 40 |
| D1222UK | 60 | 50 | 10 | 175 | 12.5 | DK | PUSH-PULL | 1-200MHz | 3+3 | 40 |
| D1231UK | 10 | 50 | 10 | 500 | 12.5 | F-0127 | SINGLE-ENDED | 1-500MHz | 1 | 40 |
| D1260UK | 40 | 50 | 10 | 175 | 12.5 | DT | SINGLE-ENDED | 1-175MHz | 4 | 40 |
